39-26-9206
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Non-RoHS Compliant 2001 Vertical GENERAL PURPOSE Connector BOARD CONNECTOR UL94V-0 1.5A 125V 3.2004mm
PDF
/
Inventory: 6717
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Width 4.3mm
Length 41.9mm
Height 6mm
Technical
UL Flammability Code 94V-0
Contact Length - Mating 3.2004mm
Current Rating 1.5A
Reach Compliance Code unknown
Orientation Vertical
Total Number of Contacts 20
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
HTS Code 8536.69.40.40
Additional Feature POLARIZED, SHROUDED
Voltage - Rated 125V
Gender Male
Number of Rows 1
Number of Positions 20
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Solder
Published 2001
Physical
Housing Material Nylon
Mount Through Hole
Contact Plating Tin
Contact Material Brass
