22-29-2051
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER VERT 5POS 2.54MM
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9405
≥1 USD $0.9405
≥10 USD $0.7714
≥100 USD $0.74765
≥500 USD $0.72295
≥1000 USD $0.6992
Inventory: 12092
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Plating Thickness 20μin
Length 7.77mm
Height 14.73mm
Technical
Glow Wire Compliant Non-compliant
Current Rating (Max) 7A
Halogen Free Low Halogen
Contact Pattern RECTANGULAR
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 250V
Body/Shell Style RECEPTACLE
Insulation Resistance 50GOhm
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Contact Gender Male
Body Breadth 0.23 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 7.493mm
Number of Contacts 5
Lead Pitch 2.54mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 4A
Depth 10.01mm
Orientation Vertical
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Fastening Type Friction
Additional Feature KK
Number of Rows 1
Color Natural
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Connector Type Male Pin
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2009
Packaging Bulk
Physical
Housing Material Nylon
Mount Through Hole
Contact Plating Gold
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
