22-28-8324
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings HEADER 32POS .100 R/A GOLD
PDF
/
Inventory: 5953
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Bronze
Contact Plating Gold
Mount Through Hole
Housing Material Nylon
Technical
Packaging Bulk
Published 2007
JESD-609 Code e3
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Male Pin
Color Black
Number of Rows 1
Gender Male
Voltage - Rated 250V
Additional Feature MATING LENGTH=0.244 INCHES
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Reach Compliance Code unknown
Current Rating 4A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Number Of PCB Rows 1
Number of Contacts 32
Contact Length - Mating 6.1976mm
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 75°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.098 inch
UL Flammability Code 94V-0
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Insulation Resistance 50000000000Ohm
Body/Shell Style RECEPTACLE
Polarization Key POLAR PIN POSITION
Durability 25 Cycles
Contact Pattern RECTANGULAR
Dimensions
Plating Thickness 30μin
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
