22-28-8024
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings KK 100 Hdr Assy RA B Bkwy 02 Ckt 30 SGold
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.212631
≥1 USD $0.212631
≥10 USD $0.200596
≥100 USD $0.189239
≥500 USD $0.178528
≥1000 USD $0.16842
Inventory: 6079
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 30μin
Width 2.29mm
Length 5.08mm
Height 2.49mm
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 250.25kV
Polarization Key POLAR PIN POSITION
Body/Shell Style RECEPTACLE
Insulation Resistance 50000000000Ohm
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Body Breadth 0.098 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.1976mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 4A
Orientation Right Angle
Total Number of Contacts 2
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Voltage - Rated 250V
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Number of Positions 2
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Physical
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Gold
Contact Material Brass
