22-28-4325
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 32POS .100 VERT GOLD
PDF
/
Inventory: 7149
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Connector Type Male Pin
Color Black
Number of Rows 1
Gender Male
Voltage - Rated 250V
Additional Feature SURFACE-MOUNT COMPATIBLE
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Reach Compliance Code unknown
Current Rating 4A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 3.2 inch
Number Of PCB Rows 1
Number of Contacts 32
Contact Length - Mating 7.493mm
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 75°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.098 inch
UL Flammability Code 94V-0
ECCN Code EAR99
Termination Solder
Pbfree Code yes
Packaging Bulk
Contact Pattern RECTANGULAR
Durability 25 Cycles
Body/Shell Style RECEPTACLE
Insulation Resistance 50000000000Ohm
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 4A
Body Depth 0.09 inch
Physical
Housing Material Polyamide
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
