22-28-4076

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description CONN HEADER 7POS .100 VERT GOLD
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.39491
≥1 USD $0.39491
≥10 USD $0.372559
≥100 USD $0.351464
≥500 USD $0.331578
≥1000 USD $0.312808
Inventory: 1142
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 2.49mm
Length 17.8mm
Height 2.29mm

Technical

Glow Wire Compliant Non-compliant
Withdrawl Force-Min .556 N
Insertion Force-Max 4.8928 N
Contact Pattern RECTANGULAR
Body/Shell Style RECEPTACLE
Contact Style SQ PIN-SKT
Body Depth 0.09 inch
UL Flammability Code 94V-0
Body Breadth 0.098 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.096mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 4A
Orientation Vertical
Total Number of Contacts 7
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature SURFACE-MOUNT COMPATIBLE
Voltage - Rated 250V
Gender Male
Number of Rows 1
Color Black
Number of Positions 7
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Pbfree Code yes
Packaging Bulk

Physical

Housing Material Thermoplastic
Mount Through Hole
Contact Plating Gold
Contact Material Brass

Alternative Model
