22-05-7135
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 13POS 2.5MM R/A TIN
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.540715
≥1 USD $0.540715
≥10 USD $0.510109
≥100 USD $0.481241
≥500 USD $0.453992
≥1000 USD $0.428298
Inventory: 8370
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Technical
Contact Pattern RECTANGULAR
Durability 30 Cycles
Polarization Key POLARIZED HOUSING
Body/Shell Style RECEPTACLE
Contact Resistance 20mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 3A
UL Flammability Code 94V-0
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 3.5052mm
Number of Contacts 13
Lead Pitch 2.5mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 3A
Orientation Right Angle
Pitch 2.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Additional Feature POLARIZED, SHROUDED
Gender Male
Number of Rows 1
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Male Pin
Termination Solder
Pbfree Code yes
Packaging Bulk
Physical
Housing Material Nylon
Mount Through Hole
Contact Plating Tin
Contact Material Brass
