22-03-5075
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 7POS 2.5MM VERT TIN
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.350412
≥1 USD $0.350412
≥10 USD $0.330581
≥100 USD $0.311863
≥500 USD $0.294215
≥1000 USD $0.277567
Inventory: 6143
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Length 19.9mm
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Durability 30 Cycles
Polarization Key POLARIZED HOUSING
Body/Shell Style RECEPTACLE
Insulation Resistance 1GOhm
Contact Resistance 20mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 3A
Housing Color Natural
UL Flammability Code 94V-0
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 3.5052mm
Number of Contacts 7
Lead Pitch 2.5mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 3A
Depth 4.9mm
Orientation Vertical
Pitch 2.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Additional Feature SPOX, POLARIZED, SHROUDED
Gender Male
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Male Pin
Termination Solder
Part Status Active
Pbfree Code yes
Published 2002
Physical
Housing Material Nylon
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 12 Weeks
