22-03-5035
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Shrouded Header HDR 3 POS 2.5mm Solder ST Thru-Hole SPOX? Bag
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.1881
≥1 USD $0.1881
≥10 USD $0.15485
≥100 USD $0.1501
≥500 USD $0.14535
≥1000 USD $0.1406
≥10000 USD $0.1254
Inventory: 1359
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 4.9mm
Length 9.9mm
Height 5.9mm
Technical
Voltage - Working 250V
Glow Wire Compliant Non-compliant
Voltage - Test 1kV
Insulator Color NATURAL
Contact Pattern RECTANGULAR
Polarization Key POLARIZED HOUSING
Body/Shell Style RECEPTACLE
Insulation Resistance 1GOhm
Contact Resistance 20mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Contact Gender Male
PCB Contact Pattern RECTANGULAR
Number of Contacts 3
Lead Pitch 2.5mm
Number Of PCB Rows 1
Shrouding Yes
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 3A
Orientation Vertical
Pitch 2.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Additional Feature SPOX, POLARIZED, SHROUDED
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2002
Packaging Bulk
Physical
Housing Material Nylon
Mount PCB, Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 12 Weeks
