1719771216
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Rectangular Connector Header
PDF
/
Inventory: 5693
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Brass
Mounting Type Surface Mount, Right Angle
Contact Shape Circular
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -40°C~105°C
Series SL 171977
Feature Board Guide, Polarizing Key
Part Status Active
Termination Solder
Connector Type Header
Number of Positions 16
Number of Rows 1
Voltage - Rated 250V
Fastening Type Latch Holder
Contact Finish - Mating Gold
Contact Type Male Pin
Current Rating (Amps) 3A
Insulation Height 0.276 7.00mm
Style Board to Cable/Wire
Number of Positions Loaded All
Reach Compliance Code compliant
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Shrouding Shrouded - 4 Wall
Contact Finish - Post Tin
Contact Length - Mating 0.240 6.10mm
Dimensions
Contact Finish Thickness - Mating 29.5μin 0.75μm
Contact Finish Thickness - Post 78.7μin 2.00μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
