15-29-6060
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings Obsolete
PDF
/
Inventory: 2614
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 15μin
Width 10.7mm
Length 79mm
Height 12.1mm
Technical
Contact Pattern RECTANGULAR
Durability 50 Cycles
Polarization Key CENTER
Body/Shell Style RECEPTACLE
Insulation Resistance 1000000000Ohm
Contact Resistance 15mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.475 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Body Breadth 0.405 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 5.08mm
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 3A
Reach Compliance Code unknown
Orientation Vertical
Total Number of Contacts 60
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature LATCHED, POLARIZED
Voltage - Rated 250V
Gender Male
Number of Rows 2
Color Black
Number of Positions 60
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
JESD-609 Code e3
Physical
Housing Material Polyester
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
