1053122104
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Nano-Fit 105312 2016 Board Lock Tin Connector Header -40C~105C 250V 59.0muin 1.50mum
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.210075
≥1 USD $1.210075
≥10 USD $1.141574
≥100 USD $1.076963
≥500 USD $1.015996
≥1000 USD $0.958495
Inventory: 1926
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Brass
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -40°C~105°C
Packaging Tray
Published 2016
Series Nano-Fit 105312
Feature Board Lock
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Header
Number of Positions 4
Applications Automotive, General Purpose, Industrial, Medical, Military, Telecommunications
Number of Rows 2
Voltage - Rated 250V
Fastening Type Latch Holder
Contact Finish - Mating Tin
Contact Type Male Pin
Insulation Height 0.356 9.05mm
Style Board to Cable/Wire
Number of Positions Loaded All
Pitch - Mating 0.098 2.50mm
Insulation Color Natural
Row Spacing - Mating 0.098 (2.50mm)
Contact Length - Post 0.126 3.20mm
Shrouding Shrouded - 4 Wall
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Contact Finish Thickness - Post 59.0μin 1.50μm
Stack Height (Mating) 21.30mm
