10-89-4266
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings CGrid R/A Bkwy HPro Hdr 30 SAu 26Ckt
PDF
/
Inventory: 9931
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Insulation Resistance 1000000000Ohm
Body/Shell Style RECEPTACLE
ELV Compliant
Dielectric Withstanding Voltage 600VAC V
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.096mm
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 3A
Orientation Right Angle
Total Number of Contacts 26
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature C-GRID, HIGH PROFILE
Voltage - Rated 250V
Gender Male
Number of Rows 2
Color Black
Number of Positions 26
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Dimensions
Height 5.59mm
Length 32.8mm
Width 2.29mm
Plating Thickness 30μin
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
Physical
Housing Material Polyester
Material Brass
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
