10-89-2121
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
BREAKAWAY TYPE Rectangular Connector Header
PDF
/
Inventory: 1849
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Operating Temperature (Min) -40°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.096mm
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Reach Compliance Code unknown
Orientation Vertical
Total Number of Contacts 12
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature BREAKAWAY TYPE
Gender Male
Number of Rows 2
Color Black
Number of Positions 12
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Published 2005
Packaging Bulk
Contact Pattern RECTANGULAR
Durability 50 Cycles
Dielectric Withstanding Voltage 600VAC V
Body/Shell Style RECEPTACLE
Insulation Resistance 1000000000Ohm
Contact Resistance 15mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.09 inch
UL Flammability Code 94V-0
Physical
Housing Material Plastic
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 30μin
Width 5.08mm
Length 15mm
Height 2.29mm
