10-89-2061
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 2x3 VERT HDR 30u Au
PDF
/
Inventory: 2680
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.11 inch
Plating Thickness 30μin
Technical
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 250.25kV
Durability 50 Cycles
Body/Shell Style RECEPTACLE
Insulation Resistance 1000000000Ohm
Contact Resistance 15mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.09 inch
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.096mm
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 3A
Orientation Vertical
Total Number of Contacts 6
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature BREAKAWAY TYPE
Voltage - Rated 250V
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 6
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Published 2005
Physical
Housing Material Polyester
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
