10-02-1047
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
MOLEX 10-02-1047Wire-To-Board Connector, Through Hole, Header, 4 Contacts, 5.08 mm, Tin Plated Contacts
PDF
/
Inventory: 6998
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Length 19.24mm
Technical
Withdrawl Force-Min .973 N
Insertion Force-Max 9.7856 N
Contact Pattern RECTANGULAR
Durability 30 Cycles
Max Voltage Rating (AC) 250V
Body/Shell Style RECEPTACLE
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 7A
Body Breadth 0.25 inch
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 10.6426mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 7A
Depth 6.35mm
Orientation Vertical
Total Number of Contacts 4
Pitch 5.08mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature SPOX
Voltage - Rated 250V
Gender Male
Number of Rows 1
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 4
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Published 2001
Physical
Housing Material Nylon
Mount Through Hole
Contact Plating Tin
Contact Material Brass
