0906633203

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description QF50 SRD HDR RA KEY .25AU 20POS
PDF
/
Inventory: 8860
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Shrouding Shrouded - 4 Wall
Number of Contacts 20
Contact Finish - Post Tin
Contact Length - Mating 0.200 5.08mm
Number of Circuits 20
Contact Length - Post 0.138 3.50mm
Row Spacing - Mating 0.100 (2.54mm)
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Current Rating 2.5A
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.335 8.51mm
Pitch 2.54mm
Contact Type Male Pin
Contact Finish - Mating Gold
Fastening Type Latch Lock/Eject Hooks
Number of Rows 2
Color Black
Number of Positions 20
Connector Type Header
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Mounting Flange
Series QF 50 90663
Packaging Bulk

Dimensions

Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 118.1μin 3.00μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant

Physical

Insulation Material Polyester, Glass Filled
Contact Shape Square
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold
Contact Material Brass
