0906270761
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Rectangular Connector Header
PDF
/
Inventory: 6089
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Number of Positions 1
Applications Automotive, General Purpose
Number of Rows 1
Fastening Type Push-Pull
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Terminal Pitch 2.54mm
Insulation Height 0.098 2.50mm
Style Board to Cable/Wire
Number of Positions Loaded All
Insulation Color Black
Contact Length - Post 0.114 2.90mm
Shrouding Unshrouded
Contact Finish - Post Tin
Contact Length - Mating 0.266 6.75mm
Overall Contact Length 0.478 12.15mm
Connector Type Header, Breakaway
Termination Kinked Pin, Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series C-Grid III 90627
Packaging Bulk
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Physical
Insulation Material Polyester, Glass Filled
Contact Shape Square
Mounting Type Through Hole
Contact Material Brass
