0901361115
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Shrouded Header HDR 15 POS 2.54mm Solder ST Thru-Hole C-Grid III? Tray
PDF
/
Inventory: 7881
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 118.1μin 3.00μm
Length 41.45mm
Technical
Number of Circuits 14
Overall Contact Length 0.510 12.95mm
Housing Color Black
Contact Length - Mating 0.266 6.75mm
Shrouding Shrouded - 4 Wall
Contact Length - Post 0.114 2.90mm
Pitch - Mating 0.100 2.54mm
Current Rating 3A
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.429 10.90mm
Depth 7.21mm
Orientation Vertical
Contact Type Male Pin
Contact Finish - Mating Tin
Fastening Type Latch Holder
Number of Rows 1
Applications Automotive, General Purpose
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 15
Connector Type Header
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series C-Grid III 90136
Packaging Tray
Physical
Housing Material Polyester
Insulation Material Polyester, Glass Filled
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
