0901210144
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Unshrouded Header HDR 24 POS 2.54mm Solder RA Thru-Hole C-Grid III? Bag
PDF
/
Inventory: 5589
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Mount Through Hole
Mounting Type Through Hole, Right Angle
Contact Shape Square
Insulation Material Polyester, Glass Filled
Housing Material Polyester
Technical
Packaging Tray
Series C-Grid III 90121
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header, Breakaway
Number of Positions 24
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Applications Automotive, General Purpose
Number of Rows 1
Fastening Type Push-Pull
Contact Finish - Mating Tin
Contact Type Male Pin
Orientation Right Angle
Depth 11mm
Insulation Height 0.142 3.60mm
Style Board to Board or Cable
Number of Positions Loaded All
Reach Compliance Code unknown
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Contact Length - Post 0.114 2.90mm
Shrouding Unshrouded
Contact Length - Mating 0.266 6.75mm
Housing Color Black
Contact Resistance 20mOhm
Number of Circuits 23
Dimensions
Length 60.96mm
Contact Finish Thickness - Mating 118.1μin 3.00μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
