0878343011
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 5256
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyamide (PA46), Nylon 4/6, Glass Filled
Material Nylon
Technical
Packaging Tray
Series C-Grid 87834
Feature Board Guide, Keying Slot
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header
Number of Positions 30
Color Beige
Applications Automotive, General Purpose, Lighting, Medical, Telecommunications
Number of Rows 2
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Type Male Pin
Pitch 2.54mm
Orientation Vertical
Insulation Height 0.365 9.27mm
Style Board to Cable/Wire
Number of Positions Loaded All
Current Rating 2.5A
Pitch - Mating 0.100 2.54mm
Insulation Color Beige
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.135 3.43mm
Shrouding Shrouded - 4 Wall
Number of Contacts 30
Contact Finish - Post Tin
Contact Length - Mating 0.240 6.10mm
Overall Contact Length 0.490 12.45mm
Number of Circuits 26
Dimensions
Contact Finish Thickness - Mating 5.11μin 0.130μm
Contact Finish Thickness - Post 98.4μin 2.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
