0878311242

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Conn Shrouded Header HDR 12 POS 2mm Solder ST Thru-Hole Milli-Grid? Tube
PDF
/
Buying Options
Total Price: USD $1.28
Unit Price: USD $1.2848
≥1 USD $1.2848
≥10 USD $1.093893
≥100 USD $0.903549
≥500 USD $0.837258
Inventory: 25666
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Post 74.8μin 1.90μm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Length 14.65mm

Technical

Housing Color Black
Contact Length - Mating 0.141 3.60mm
Contact Finish - Post Tin
Number of Contacts 12
Shrouding Shrouded - 4 Wall
Contact Length - Post 0.098 2.50mm
Row Spacing - Mating 0.079 (2.00mm)
Pitch - Mating 0.079 2.00mm
Current Rating 2A
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.252 6.40mm
Depth 6.3mm
Orientation Vertical
Contact Type Male Pin
Contact Finish - Mating Gold
Fastening Type Push-Pull
Number of Rows 2
Applications Automotive, General Purpose, Telecommunications
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Header
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Milli-Grid 87831
Packaging Tube

Physical

Housing Material Nylon
Insulation Material Polyamide (PA), Nylon, Glass Filled
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 10 Weeks
