0559320910

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description MicroClasp 55932 ROHS3Compliant Board Guide Tin Connector Header 0.144 3.66mm
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.6688
≥100 USD $0.557594
≥500 USD $0.418229
≥1000 USD $0.390342
≥3000 USD $0.370823
Inventory: 1505
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Stack Height (Mating) 13.2mm

Technical

Overall Contact Length 0.360 9.15mm
Contact Length - Mating 0.144 3.66mm
Shrouding Shrouded - 4 Wall
Contact Length - Post 0.126 3.20mm
Insulation Color Natural
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.384 9.75mm
Terminal Pitch 2mm
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Tin
Fastening Type Latch Holder
Number of Rows 1
Applications General Purpose, Industrial, Medical
Number of Positions 9
Connector Type Header
Termination Kinked Pin, Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
JESD-609 Code e3
Series MicroClasp 55932
Packaging Tray

Physical

Insulation Material Polybutylene Terephthalate (PBT)
Contact Shape Square
Mounting Type Through Hole
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 17 Weeks
