0554560769
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Shrouded Header HDR 7 POS 1.25mm Solder RA SMD Mini Mi II? Embossed T/R
PDF
/
Inventory: 6978
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Package / Case SMD/SMT
Contact Shape Square
Insulation Material Polyamide (PA), Nylon
Housing Material Nylon
Technical
Packaging Tape & Reel (TR)
Series Mini Mi II 55456
JESD-609 Code e3
Feature Solder Retention
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Number of Rows 1
Additional Feature POLARIZED
Fastening Type Push-Pull
Contact Finish - Mating Tin
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Orientation Right Angle
Insulation Height 0.177 4.50mm
Style Board to Cable/Wire
Number of Positions Loaded All
Current Rating 1.5A
Pitch - Mating 0.049 1.25mm
Insulation Color Natural
Voltage - Rated AC 100V
Shrouding Shrouded - 4 Wall
Number of Contacts 7
Contact Length - Mating 0.110 2.79mm
Contact Gender Male
Max Voltage Rating (DC) 100.1kV
Mating Post Length 5.55mm
Glow Wire Compliant Non-compliant
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
