0554560759
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
1.25mm Pitch Mi ll System Wire-to-Board Header, Single Row, Right Angle, SMT, 7 Circuits, with Plastic Peg, Lead-Free
PDF
/
Inventory: 9841
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length 12.4mm
Technical
Max Voltage Rating (DC) 100V
Max Voltage Rating (AC) 100V
Number of Circuits 6
Contact Resistance 20mOhm
Housing Color Natural
Contact Length - Mating 0.110 2.79mm
Shrouding Shrouded - 4 Wall
Pitch - Mating 0.049 1.25mm
Current Rating 1.5A
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.177 4.50mm
Depth 8.15mm
Orientation Right Angle
Total Number of Contacts 7
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Tin
Fastening Type Push-Pull
Additional Feature POLARIZED
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 7
Connector Type Header
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide, Solder Retention
JESD-609 Code e3
Series Mini Mi II 55456
Packaging Tape & Reel (TR)
Physical
Housing Material Nylon
Insulation Material Polyamide (PA), Nylon
Contact Shape Square
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Material Brass
