0554514070

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Headers & Wire Housings Mini Mi2 Str 2-Row W Row Wafer Assy 40Ckt
PDF
/
Inventory: 3044
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Brass
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyamide (PA), Nylon

Technical

Packaging Tray
Series Mini Mi II 55451
Feature Board Guide
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header
Number of Positions 40
Number of Rows 2
Fastening Type Push-Pull
Contact Finish - Mating Tin
Contact Type Male Pin
Insulation Height 0.386 9.80mm
Style Board to Cable/Wire
Number of Positions Loaded All
Pitch - Mating 0.049 1.25mm
Insulation Color Natural
Row Spacing - Mating 0.079 (2.00mm)
Contact Length - Post 0.118 3.00mm
Shrouding Shrouded - 4 Wall
Contact Length - Mating 0.130 3.30mm
Overall Contact Length 0.343 8.70mm

Dimensions

Stack Height (Mating) 9.8mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
