0532682091
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 6129
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Contact Shape Square
Insulation Material Polyamide (PA46), Nylon 4/6
Technical
Packaging Tape & Reel (TR)
Series 53268
Feature Solder Retention
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header
Number of Positions 20
Number of Rows 2
Fastening Type Push-Pull
Contact Finish - Mating Tin
Contact Type Male Pin
Insulation Height 0.173 4.40mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.039 1.00mm
Row Spacing - Mating 0.057 (1.45mm)
Shrouding Shrouded - 4 Wall
Contact Length - Mating 0.075 1.90mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
