0449142202
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Power HDR 22 POS 3mm Press Fit ST Thru-Hole 22 Terminal 1 Port Tray
PDF
/
Inventory: 980
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Modified Tin/Brass Alloy
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP), Glass Filled
Technical
Packaging Tray
Series Micro-Fit 3.0 CPI 44914
Feature Board Guide
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit, Solder
Connector Type Header
Number of Positions 22
Applications General Purpose, Medical, Military, Telecommunications
Number of Rows 2
Fastening Type Locking Ramp
Contact Finish - Mating Gold
Contact Type Male Pin
Insulation Height 0.390 9.91mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.118 3.00mm
Insulation Color Black
Row Spacing - Mating 0.118 (3.00mm)
Contact Length - Post 0.125 3.18mm
Shrouding Shrouded - 4 Wall
Contact Finish - Post Tin-Lead
Dimensions
Contact Finish Thickness - Mating 15.0μin 0.38μm
Contact Finish Thickness - Post 60.0μin 1.52μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
