0438790027
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Power HDR 14 POS 4.2mm Press Fit ST Thru-Hole 14 Terminal 1 Port Mini-Fit? BMI Tray
PDF
/
Buying Options
Total Price: USD $8.39
Unit Price: USD $8.3864
≥1 USD $8.3864
≥10 USD $7.4316
≥100 USD $6.71
Inventory: 1512
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyamide (PA), Nylon, Glass Filled
Shell Material POLYETHYLENE
Technical
Packaging Tray
Series Mini-Fit BMI/CPI 43879
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit, Solder
Connector Type Header
Number of Positions 14
Applications General Purpose, Industrial, Medical, Telecommunications
Number of Rows 2
Additional Feature POLARIZED
Fastening Type Push-Pull
Contact Finish - Mating Tin
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Insulation Height 0.587 14.91mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.165 4.20mm
Insulation Color Black
Row Spacing - Mating 0.165 (4.20mm)
Contact Length - Post 0.246 6.25mm
Shrouding Shrouded - 4 Wall
UL Flammability Code 94V-0
Empty Shell NO
Dimensions
Contact Finish Thickness - Mating 100.0μin 2.54μm
Contact Finish Thickness - Post 100.0μin 2.54μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
