0432420005
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Rectangular Connector Header
PDF
/
Buying Options
Total Price: USD $1.19
Unit Price: USD $1.188
≥1 USD $1.188
≥10 USD $0.98296
≥100 USD $0.818937
≥500 USD $0.655151
≥1000 USD $0.573258
≥3000 USD $0.544597
Inventory: 6482
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Brass
Contact Plating Copper, Tin
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyamide (PA66), Nylon 6/6
Housing Material Nylon
Technical
Packaging Bulk
Series Mini-Fit Jr 43242
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Solder
Connector Type Header
Number of Positions 3
Color Natural
Applications General Purpose, Industrial, Telecommunications
Number of Rows 1
Fastening Type Locking Ramp
Contact Finish - Mating Tin
Contact Type Male Pin
Pitch 4.2mm
Orientation Straight
Depth 5.4mm
Insulation Height 0.490 12.44mm
Style Board to Cable/Wire
Number of Positions Loaded All
Pitch - Mating 0.165 4.20mm
Insulation Color Natural
Contact Length - Post 0.146 3.70mm
Shrouding Shrouded - 4 Wall
Number of Contacts 3
Contact Finish - Post Tin
Housing Color Natural
Number of Ports 1
Dimensions
Length 23.8mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
