0430451815

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Conn Wire to Board HDR 18 POS 3mm Solder ST SMD Micro-Fit 3.0? Embossed T/R
PDF
/
Inventory: 3037
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Mating 60.0μin 1.52μm

Technical

Glow Wire Compliant Compliant
Halogen Free Low Halogen
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender Male
Number of Contacts 18
Shrouding Shrouded - 4 Wall
Row Spacing - Mating 0.118 (3.00mm)
Insulation Color Black
Pitch - Mating 0.118 3.00mm
Current Rating 5A
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.390 9.91mm
Orientation Vertical
Current Rating (Amps) 8A
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Tin
Fastening Type Locking Ramp
HTS Code 8536.69.40.30
Additional Feature MICRO-FIT 3.0, POLARIZED, SHROUDED
Voltage - Rated 600V
Number of Rows 2
Applications General Purpose, Medical, Military, Telecommunications
Connector Type Header
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Lock
Series Micro-Fit 3.0 43045
Packaging Tape & Reel (TR)

Physical

Housing Material Polymer
Shell Material POLYETHYLENE
Insulation Material Liquid Crystal Polymer (LCP), Glass Filled
Contact Shape Square
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Brass

Supply Chain

Factory Lead Time 6 Weeks
