0428196232

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Conn Wire to Board HDR 6 POS 10mm Solder ST Thru-Hole Mini-Fit Sr? Tray
PDF
/
Inventory: 8969
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Post 100.0μin 2.54μm
Contact Finish Thickness - Mating 100.0μin 2.54μm

Technical

Empty Shell NO
UL Flammability Code 94V-0
Shrouding Shrouded - 4 Wall
Contact Length - Post 0.201 5.11mm
Insulation Color Black
Pitch - Mating 0.394 10.00mm
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.827 21.00mm
Mixed Contacts NO
Contact Type Male Blade
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Tin
Fastening Type Locking Ramp
Additional Feature POLARIZED
Number of Rows 1
Applications Automotive, General Purpose, Industrial, Medical, Telecommunications
Number of Positions 6
Connector Type Header
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Board Lock
Series Mini-Fit Sr 42819
Packaging Tray

Physical

Shell Material POLYETHYLENE
Insulation Material Polyamide (PA46), Nylon 4/6, Glass Filled
Contact Shape Rectangular
Mounting Type Through Hole
Contact Material Copper Zirconium Alloy
