0026626082
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Rectangular Connector Header
PDF
/
Inventory: 2533
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyester, Glass Filled
Technical
Packaging Bulk
Series KK 42891
Feature Board Lock
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header
Number of Positions 10
Color Natural
Applications Automotive, General Purpose, Industrial, Medical, Telecommunications
Number of Rows 1
Fastening Type Friction Lock
Contact Finish - Mating Tin
Contact Type Male Pin
Pitch 3.9624mm
Insulation Height 0.446 11.33mm
Style Board to Board or Cable
Number of Positions Loaded 9
Pitch - Mating 0.156 3.96mm
Insulation Color Natural
Contact Length - Post 0.140 3.56mm
Shrouding Shrouded - 1 Wall
Contact Finish - Post Tin
Contact Length - Mating 0.450 11.43mm
Overall Contact Length 0.720 18.29mm
Dimensions
Contact Finish Thickness - Mating 60.0μin 1.52μm
Contact Finish Thickness - Post 60.0μin 1.52μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
