0010897022

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Male Pin Rectangular Connector
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.3652
≥100 USD $0.283888
≥500 USD $0.223027
≥1000 USD $0.195994
≥3000 USD $0.182477
Inventory: 7659
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Post 74.8μin 1.90μm
Contact Finish Thickness - Mating 15.0μin 0.38μm

Technical

Overall Contact Length 0.437 11.10mm
Contact Length - Mating 0.240 6.10mm
Contact Finish - Post Tin
Shrouding Unshrouded
Contact Length - Post 0.107 2.71mm
Row Spacing - Mating 0.100 (2.54mm)
Insulation Color Black
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.090 2.29mm
Contact Type Male Pin
Contact Finish - Mating Gold
Fastening Type Push-Pull
Applications Automotive, General Purpose, Lighting, Medical, Telecommunications
Number of Positions 2
Connector Type Header, Breakaway
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series C-Grid 70280
Packaging Bulk

Physical

Insulation Material Liquid Crystal Polymer (LCP), Glass Filled
Contact Shape Square
Mounting Type Through Hole
Contact Material Copper Alloy
