LY20-8P-DLT1-P1E-BR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
LY20 RoHS Compliant 2009 Right Angle Connector Header -40C~85C 3A per Contact 250V 3.90muin 0.099mum
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2144
≥1 USD $1.2144
≥10 USD $1.02344
≥100 USD $0.918984
≥500 USD $0.668378
≥1000 USD $0.58483
≥3000 USD $0.555588
Inventory: 672
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 3.90μin 0.099μm
Technical
Contact Gender Male
Contact Length - Mating 0.106 2.70mm
Contact Finish - Post Tin
Shrouding Shrouded - 4 Wall
Contact Length - Post 0.118 3.00mm
Row Spacing - Mating 0.079 (2.00mm)
Insulation Color Brown
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.209 5.30mm
Orientation Right Angle
Current Rating (Amps) 3A per Contact
Contact Type Male Pin
Contact Finish - Mating Gold
Fastening Type Detent Lock
Voltage - Rated 250V
Number of Rows 2
Number of Positions 8
Connector Type Header
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LY20
Published 2009
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Housing Material Nylon
Insulation Material Polyamide (PA66), Nylon 6/6, Glass Filled
Contact Shape Square
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 14 Weeks
