IL-Z-7PL-SMTYE
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 7P Pin Header 1.25mm R/A SMT
PDF
/
Inventory: 2685
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Wire Gauge (Min) 30 AWG
Wire Gauge (Max) 28 AWG
Insulation Resistance 100MOhm
Contact Gender Male
Contact Length - Mating 0.108 2.75mm
Contact Finish - Post Tin
Number of Contacts 7
Lead Pitch 1.25mm
Shrouding Shrouded - 4 Wall
Insulation Color Beige
Pitch - Mating 0.049 1.25mm
Current Rating 1A
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.136 3.46mm
Orientation Right Angle
Pitch 1.25mm
Current Rating (Amps) 1A per Contact
Contact Type Male Pin
Contact Finish - Mating Tin
Fastening Type Push-Pull
Voltage - Rated 200V
Gender Female
Number of Rows 1
Color Beige, Brown
Number of Positions 7
Connector Type Header
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Solder Retention
Series IL-Z
Published 2008
Packaging Tray
Operating Temperature -40°C~70°C
Physical
Housing Material Nylon
Insulation Material Polyphenylene Sulfide (PPS)
Contact Shape Square
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Tin
Contact Material Brass
Alternative Model
