M80-8460642
RoHS
RoHS compliant
RoHS compliantPackage SIL
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
6 Pos Sil Horiz Pc Tail F/lock
PDF
/
Inventory: 5705
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 118.1μin 3.00μm
Contact Finish Thickness - Mating 29.5μin 0.75μm
Plating Thickness 30μin
Length 15.6mm
Technical
Insertion Force-Max 2.78 N
Durability 500 Cycles
Max Current Rating 3A
Max Voltage Rating (AC) 120V
Mating Contact Pitch 0.079 inch
Contact Resistance 25mOhm
UL Flammability Code 94V-0
Contact Gender Male
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 1
Shrouding Shrouded - 4 Wall
Contact Length - Post 0.118 3.00mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.156 3.96mm
Terminal Pitch 2mm
Orientation Right Angle
Current Rating (Amps) 2.2A
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Friction Lock
Additional Feature LATCHED
Number of Rows 1
Number of Positions 6
Connector Type Plug
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Strain Relief Clips
JESD-609 Code e3
Series Datamate L-Tek
Published 2011
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Housing Material Polyamide
Insulation Material Polyester, Glass Filled
Contact Shape Circular
Package / Case SIL
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 9 Weeks
