M80-8410845
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
ROHS COMPLIANT Male Pin Rectangular Connector
PDF
/
Inventory: 3106
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 29.5μin 0.75μm
Plating Thickness 30μin
Technical
Durability 500 Cycles
Mating Contact Pitch 0.079 inch
Insulation Resistance 100000000Ohm
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Shrouding Shrouded - 4 Wall
Contact Length - Post 0.118 3.00mm
Row Spacing - Mating 0.079 (2.00mm)
Body Length or Diameter 0.455 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.235 5.97mm
Current Rating (Amps) 2.2A
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Latch Holder
Additional Feature ROHS COMPLIANT
Voltage - Rated 120V
Number of Rows 2
Number of Positions 8
Connector Type Header
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Feature Strain Relief Clips
JESD-609 Code e4
Series Datamate L-Tek
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Mounting Option 1 LOCKING
Insulation Material Polyamide (PA46), Nylon 4/6
Contact Shape Circular
Mounting Type Through Hole, Right Angle
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 11 Weeks
