M80-5220622
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 3+3 WAY MALE VERT SMT W/O JS
PDF
/
Inventory: 6772
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Stack Height (Mating) 7.55mm 7.95mm 10.1mm 11.1mm 13.65mm 15.1mm
Contact Finish Thickness - Post 118.1μin 3.00μm
Contact Finish Thickness - Mating 29.5μin 0.75μm
Plating Thickness 30μin
Technical
Durability 500 Cycles
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.079 inch
Insulation Resistance 100000000Ohm
UL Flammability Code 94V-0
Mating Information NS
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin-Lead
Number Of PCB Rows 2
Shrouding Shrouded - 4 Wall
Row Spacing - Mating 0.079 (2.00mm)
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Reach Compliance Code not_compliant
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.220 5.60mm
Total Number of Contacts 6
Current Rating (Amps) 2.2A
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Additional Feature PANEL MOUNTABLE
Voltage - Rated 800V
Number of Rows 2
Number of Positions 6
Connector Type Header
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Keying Slot, Mating Flange
JESD-609 Code e0
Series Datamate J-Tek
Published 2013
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Mounting Option 2 JACKSCREW
Mounting Option 1 LOCKING
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Contact Shape Circular
Mounting Type Surface Mount
Contact Material Phosphor Bronze
