M80-5122042
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Datamate J-Tek ROHS3Compliant COMMERCIAL UL Connector Header 500Cycles 25mOhm -55C~125C 3A
PDF
/
Buying Options
Total Price: USD $17.8
Unit Price: USD $17.8024
≥1 USD $17.8024
≥10 USD $15.425854
≥100 USD $12.713378
≥500 USD $11.611565
Inventory: 335
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Stack Height (Mating) 7.55mm 7.95mm 10.1mm 11.1mm 13.65mm 15.1mm
Contact Finish Thickness - Post 118.1μin 3.00μm
Contact Finish Thickness - Mating 29.5μin 0.75μm
Plating Thickness 30μin
Length 30mm
Technical
Max Voltage Rating (DC) 120V
Durability 500 Cycles
Polarization Key POLARIZED HOUSING
Max Current Rating 3A
Max Voltage Rating (AC) 120V
Mating Contact Pitch 0.079 inch
Insulation Resistance 100000000Ohm
Contact Resistance 25mOhm
Housing Color Black
UL Flammability Code 94V-0
Contact Gender Male
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 2
Shrouding Shrouded - 4 Wall
Row Spacing - Mating 0.079 (2.00mm)
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Pitch - Mating 0.079 2.00mm
Current Rating 3A
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.234 5.95mm
Depth 6.05mm
Orientation Straight
Total Number of Contacts 20
Current Rating (Amps) 2.2A
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Threaded
HTS Code 8536.69.40.40
Voltage - Rated 800V
Number of Rows 2
Number of Positions 20
Connector Type Header
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
JESD-609 Code e3
Series Datamate J-Tek
Published 2009
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Housing Material Polyphenylene
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Contact Shape Circular
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 9 Weeks
