M50-3600342
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Unshrouded Header HDR 6 POS 1.27mm Solder ST SMD Tray
PDF
/
Buying Options
Total Price: USD $1.27
Unit Price: USD $1.2672
≥1 USD $1.2672
≥10 USD $1.10264
≥100 USD $0.985512
≥500 USD $0.680469
≥1000 USD $0.624149
≥3000 USD $0.610069
Inventory: 7610
Minimum: 1
-
+
Technical Details
Physical
Contact Shape Square
Insulation Material Thermoplastic
Mounting Option 1 LOCKING
Mounting Type Surface Mount
Contact Material Copper Alloy
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Published 2013
Series Archer M50
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header
Number of Positions 6
Number of Rows 2
Gender Male
Additional Feature ROHS COMPLIANT
Fastening Type Push-Pull
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 6
Orientation Straight
Depth 3.41mm
Insulation Height 0.039 1.00mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.050 1.27mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 0.050 (1.27mm)
Shrouding Unshrouded
Number Of PCB Rows 2
Contact Finish - Post Tin
Contact Length - Mating 0.118 3.00mm
PCB Contact Pattern RECTANGULAR
Body Breadth 0.134 inch
UL Flammability Code 94V-0
Rated Current (Signal) 1A
Contact Resistance 30mOhm
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.05 inch
Max Current Rating 1A
Dielectric Withstanding Voltage 1000VAC V
Durability 300 Cycles
Supply Chain
Factory Lead Time 13 Weeks
Dimensions
Length 3.81mm
Contact Finish Thickness - Mating 3.00μin 0.076μm
Contact Finish Thickness - Post 98.4μin 2.50μm
Stack Height (Mating) 3.9mm 5.3mm 6.08mm 6.18mm 7mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
