M40-4010846

Harwin Inc.
RoHS
RoHS RoHS compliant
Package SIL
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Headers & Wire Housings 8P SIL SMT HORIZ SHROUDED TAB HEADER
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.600475
≥1 USD $0.600475
≥10 USD $0.566488
≥100 USD $0.534421
≥500 USD $0.504167
≥1000 USD $0.475628
Inventory: 3835
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Contact Material Phosphor Bronze
Mount PCB, Surface Mount
Mounting Type Surface Mount, Right Angle
Package / Case SIL
Contact Shape Rectangular
Insulation Material Polyamide (PA9T), Nylon 9T
Material Thermoplastic
Housing Material Nylon
Weight 156.007426mg

Technical

Operating Temperature -25°C~85°C
Packaging Bulk
Published 2004
Series M40
JESD-609 Code e3
Feature Solder Retention
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header
Number of Positions 8
Number of Rows 1
Gender Male
Additional Feature SIDE ENTRY
Fastening Type Push-Pull
Contact Finish - Mating Tin
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 8
Orientation Right Angle
Depth 5mm
Insulation Height 0.114 2.90mm
Style Board to Cable/Wire
Number of Positions Loaded All
Current Rating 1A
Pitch - Mating 0.039 1.00mm
Insulation Color Natural
Voltage - Rated AC 50V
Shrouding Shrouded - 4 Wall
UL Flammability Code 94V-0
Contact Resistance 30mOhm
Insulation Resistance 100MOhm
Max Voltage Rating (AC) 50V
Max Current Rating 1A

Dimensions

Length 9mm

Compliance

Material Flammability Rating UL94 V-0
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
