M22-5322546P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 25+25DIL SMT PIN HDR PICK/PLACE CAP
PDF
/
Inventory: 3679
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Surface Mount
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Polyamide (PA6T), Nylon 6T
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Published 2010
Series M22
JESD-609 Code e3
Feature Pick and Place
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Header, Cuttable
Number of Positions 50
Number of Rows 2
Additional Feature ROHS COMPLIANT
HTS Code 8536.69.40.40
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Tin
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 1A per Contact
Total Number of Contacts 50
Insulation Height 0.059 1.50mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 1.969 inch
Row Spacing - Mating 0.079 (2.00mm)
Shrouding Unshrouded
Number Of PCB Rows 2
Contact Length - Mating 0.138 3.50mm
PCB Contact Pattern RECTANGULAR
Body Breadth 0.157 inch
UL Flammability Code 94V-0
Body Depth 0.098 inch
Contact Resistance 30mOhm
Insulation Resistance 100000000Ohm
Mating Contact Pitch 0.079 inch
PCB Contact Row Spacing 4.7498 mm
Dimensions
Stack Height (Mating) 4.6mm 6.8mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
