09195506024
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
RoHS Compliant COMMERCIAL UL POLARIZED HOUSING Connector BOARD EURO CONNECTOR 250Cycles 20mOhm 125C 2A
PDF
/
Inventory: 9811
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Mounting Type BOARD
Mounting Option 1 LATCH
Mounting Style STRAIGHT
Mounting Option 2 LOCKING
Technical
Part Status Active
Connector Type BOARD EURO CONNECTOR
Insulator Color BLACK
Mating Contact Row Spacing 0.1 inch
Contact Pattern RECTANGULAR
Contact Finish Termination TIN OVER NICKEL
Durability 250 Cycles
PCB Contact Row Spacing 2.54 mm
Polarization Key POLARIZED HOUSING
Termination Type SOLDER
Mating Contact Pitch 0.1 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 2A
Body Depth 0.681 inch
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.335 inch
Operating Temperature (Max) 125°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 3.272 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 2.54mm
Total Number of Contacts 50
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.114 inch
