09195145024
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings SEK-19 SV MA STD STR29 14P AUS4 KINK
PDF
/
Inventory: 5989
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Mounting Type BOARD
Mounting Option 1 LATCH
Mounting Style STRAIGHT
Mounting Option 2 LOCKING
Technical
JESD-609 Code e3
Part Status Active
Connector Type BOARD EURO CONNECTOR
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Total Number of Contacts 14
Terminal Pitch 2.54mm
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 1.472 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 125°C
Body Breadth 0.335 inch
Contact Gender MALE
Operating Temperature (Min) -55°C
Body Depth 0.681 inch
Rated Current (Signal) 2A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.1 inch
Termination Type SOLDER
Polarization Key POLARIZED HOUSING
PCB Contact Row Spacing 2.54 mm
Contact Finish Termination TIN OVER NICKEL
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.1 inch
Insulator Color BLACK
Dimensions
Plating Thickness 30μin
Length - Termination 0.114 inch
Compliance
RoHS Status RoHS Compliant
