09185347914800

HARTING
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description SEK ROHS3Compliant Keying Slot Mounting Flange Square Connector Header -55C~125C 0.228 5.80mm
PDF
/
Inventory: 4748
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polybutylene Terephthalate (PBT), Glass Filled

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Series SEK
Feature Keying Slot, Mounting Flange
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header
Number of Positions 34
Color Grey
Number of Rows 2
Fastening Type Latch Lock/Eject Hooks, Short
Contact Type Male Pin
Insulation Height 0.681 17.30mm
Style Board to Cable/Wire
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Gray
Row Spacing - Mating 0.100 (2.54mm)
Shrouding Shrouded - 4 Wall
Contact Length - Mating 0.228 5.80mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
