09185306973
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
COMMERCIAL UL POLARIZED HOUSING RECTANGULAR Connector BOARD EURO CONNECTOR 20mOhm 125C 1A 0.335inch
PDF
/
Inventory: 5058
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type BOARD
Insulation Material POLYBUTYLENE TEREPHTHALATE
Mounting Option 1 LOCKING
Mounting Style RIGHT ANGLE
Board Mounting Option SPLIT BOARD LOCK
Technical
Part Status Active
Connector Type BOARD EURO CONNECTOR
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Total Number of Contacts 30
Terminal Pitch 2.54mm
Reach Compliance Code compliant
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 2.283 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 125°C
Body Breadth 0.335 inch
Contact Gender MALE
Operating Temperature (Min) -55°C
Body Depth 0.681 inch
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Mating Contact Pitch 0.1 inch
Termination Type SOLDER
Polarization Key POLARIZED HOUSING
PCB Contact Row Spacing 2.54 mm
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.1 inch
Dimensions
Length - Termination 0.114 inch
