09185165004
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings SEK18SV ML STD STR29 RLG 16PAU0.76KINK
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.380565
≥1 USD $2.380565
≥10 USD $2.245813
≥100 USD $2.118692
≥500 USD $1.998768
≥1000 USD $1.885626
Inventory: 7822
Minimum: 1
-
+
Technical Details
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series SEK
Feature Keying Slot, Mounting Flange
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Kinked Pin, Solder
Connector Type Header
Number of Positions 16
Color Beige
Number of Rows 2
Fastening Type Latch Lock/Eject Hooks, Long
Contact Finish - Mating Gold
Contact Type Male Pin
Insulation Height 0.681 17.30mm
Style Board to Cable/Wire
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Gray
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.114 2.90mm
Shrouding Shrouded - 4 Wall
Contact Finish - Post Tin
Contact Length - Mating 0.240 6.10mm
Overall Contact Length 0.650 16.51mm
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
