81040-U10204

3M
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Headers & Wire Housings 40P STRT LOPRO 4WALL TRIPOLARIZED
PDF
/
Inventory: 5232
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Post 125.0μin 3.18μm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Width 7.87mm
Length 34.2mm
Height 10.9mm

Technical

Insulation Resistance 109Ohm
Housing Color Grey
Contact Length - Mating 0.140 3.56mm
Contact Finish - Post Tin-Lead
Lead Pitch 1.27mm
Shrouding Shrouded - 4 Wall
Contact Length - Post 0.092 2.34mm
Row Spacing - Mating 0.100 (2.54mm)
Insulation Color Gray
Pitch - Mating 0.050 1.27mm
Current Rating 500mA
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.405 10.29mm
Pitch 1.27mm
Current Rating (Amps) 0.5A
Contact Type Male Pin
Contact Finish - Mating Gold
Fastening Type Push-Pull
Number of Rows 2
Color Grey
Number of Positions 40
Connector Type Header
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Board Lock
Series 810
Published 2005
Packaging Bulk
Operating Temperature -55°C~105°C

Physical

Housing Material Polymer
Insulation Material Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Copper Alloy
