81040-600C04
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 40/MHDR/STR/SMT/PST/30 AVE/90:10
PDF
/
Inventory: 3677
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 125.0μin 3.18μm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Width 7.87mm
Length 39.6mm
Height 10.3mm
Technical
Housing Color Natural
Contact Length - Mating 0.140 3.56mm
Contact Finish - Post Tin-Lead
Shrouding Shrouded - 4 Wall
Row Spacing - Mating 0.100 (2.54mm)
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Current Rating 500mA
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.405 10.29mm
Pitch 1.27mm
Current Rating (Amps) 0.75A
Contact Type Male Pin
Contact Finish - Mating Gold
Fastening Type Push-Pull
Number of Rows 2
Color Natural
Number of Positions 40
Connector Type Header
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Board Lock
Series 810
Published 2013
Packaging Tray
Operating Temperature -55°C~105°C
Physical
Weight 1.360777kg
Housing Material Plastic
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Contact Material Copper Alloy
